Temperature transmitter

GTT210卫生型温度变送器 | Industrial Temperature Transmitter

GAIMC

The GTT210 series temperature transmitter represents the pinnacle of industrial temperature measurement technology, designed specifically for demanding applications in liquid, gas, and process industries. With exceptional accuracy, robust construction, and advanced features, it delivers reliable performance even in the harshest environments.

Product Overview

Industrial temperature measurement application

Precision Temperature Measurement

The GTT210 series utilizes Pt100 (1/3B grade) sensors with laser resistance adjustment for exceptional accuracy across a wide temperature range. Advanced compensation algorithms ensure stable performance in varying conditions.

Advanced Signal Processing

Our amplifier circuit converts sensor signals into standard outputs while maintaining signal integrity. The system features excellent anti-interference capabilities, overload protection, and minimal temperature drift.

Industrial Automation Ready

Designed specifically for industrial automation environments, the GTT210 offers multiple output options, wide power supply ranges, and robust construction suitable for various installation requirements.

Temperature transmitter in harsh environment

Robust Environmental Performance

Built to withstand extreme conditions, the GTT210 operates reliably in temperatures from -40°C to +85°C with 0-95% relative humidity, ensuring consistent performance in challenging industrial settings.

Key Advantages

⚡

Wide Voltage Range

Operates reliably with wide voltage power supply (9-36VDC depending on model) with non-linear correction for high accuracy.

🔧

Easy Installation

Designed for simple and quick installation with customizable thread or tri-clamp connections to fit various applications.

🛡️

Robust Protection

Features lightning strike prevention, frequency interference interception, and strong anti-interference capabilities.

🔌

Safety Features

Includes wiring reverse protection, over-voltage protection, and current limiting protection for enhanced operational safety.

📊

Multiple Output Options

Supports various output signals including 4-20mA, RS485, Pt100, and HART protocol for flexible integration with control systems.

🌡️

Wide Temperature Range

Available models cover temperature ranges from -200°C to +500°C, suitable for diverse industrial applications.

Technical Specifications

Model	GTT210B	GTT210H	GTT210S	GTT210W
Types	Explosion-proof	Aviation plug	Water-proof	Sanitary
Application	Petroleum, chemical industry, electric power, metallurgy, coal mining, environmental protection, etc	Petroleum, chemical, power, water treatment, food and beverage, pharmaceutical, industrial automation	Petroleum, chemical, power, water treatment, food and beverage, pharmaceutical	Medical pharmaceutical food and beverage chemical and other industries
Temperature range	-200～+500℃	-50～+150℃	-200～+500℃	-50～+150℃
Accuracy	0.25%FS、0.5%FS
Power supply	9～32VDC	9～36VDC	12～36VDC	9～36VDC
Output	4～20mA、RS485、Pt100、Hart	4～20mA、Pt100	4～20mA、RS485、Pt100	4～20mA、Pt100
Explosion-proof class	Flameproof type: Ex dⅡC T6 Gb Intrinsically safe: Ex ia ⅡC T6 Ga (current output only)	/	Intrinsically safe: Ex ia ⅡC T6 Ga (current output only)	/
Protection Class	IP66	IP67	IP68	IP69X
Installation	Thread (customizable)			Tri-clamp (customizable)
Material	Cast aluminum (housing)/304	304	304	316L
Working environment	-40 ~ +85℃, 0 ~ 95%RH(no condensation)

Industry Applications

Petroleum and chemical industry application

Petroleum & Chemical

Reliable temperature measurement in refineries, chemical plants, and petrochemical processing facilities with explosion-proof models available.

Food & Beverage

Sanitary models with IP69K protection for food processing, brewing, dairy, and beverage production with strict hygiene requirements.

Pharmaceutical

Precise temperature monitoring for pharmaceutical manufacturing, research laboratories, and clean room environments.

Water Treatment

Accurate temperature monitoring in water treatment plants, wastewater facilities, and environmental monitoring systems with waterproof models.

Frequently Asked Questions

What is the temperature range of GTT210 series? +

The temperature range varies by model: GTT210B and GTT210S have a range of -200 to +500℃, while GTT210H and GTT210W have a range of -50 to +150℃.

What output signals are available? +

Different models support various outputs including 4-20mA, RS485, Pt100, and HART protocol. Please refer to the specifications table for details.

What industries are these transmitters suitable for? +

GTT210 series transmitters are suitable for petroleum, chemical, power, water treatment, food and beverage, pharmaceutical, and various industrial automation applications.

What is the accuracy of these temperature transmitters? +

The accuracy is 0.25%FS or 0.5%FS depending on the specific model and configuration.

Do you offer custom solutions? +

Yes, with our strong research and development department and flexible manufacturing, we can provide customer-specific solutions tailored to your exact measurement requirements.

Online Message

Have questions? Need a quote? We are ready to help! Fill out the form and a member of our sales team will contact you to discuss your requirements. You can also give us a call at (86)177-9158-1665.

GTT210 Temperature Transmitter

Sanitary | ATEX Certified | 4-20mA HART RS485 PT100

4 types of products are available for selection；

-50～+150℃ | -200～+500℃；

Sanitary Type;

Explosion-proof；

Water-proof；

Aviation plug；

IP66-IP69X;
